Helical Vertical Gear Box
Supplied by Gohil Industrial Co. Gear Motors
Inline gear motor with the reduction stages and the motor on one axis. The longest of the gear motor formats but the narrowest, which matters when you are fitting between frames.
Price on request
Specification
- Ratio range
- i = 1:5 to 1:200
- Motor power
- 0.25 to 15 kW
- Input speed
- 1440 rpm, four pole
- Output torque
- up to 3,500 Nm
- Mounting
- Foot or B5 flange
- Protection
- IP55
These are typical figures for this type of unit, shown so you can see the shape of the range. Confirm the exact specification with us before ordering.
Typical applications
- Narrow conveyor frames
- Dosing screws
- Small mixers
