Worm Gear Box

Flange mounted worm unit for bolting directly to the driven machine rather than sitting on a base. Removes the coupling and the alignment job with it.

Price on request

Specification

Ratio range

i = 1:7.5 to 1:100

Power

0.12 to 7.5 kW

Centre distance

40 to 110 mm

Output torque

up to 1,200 Nm

Mounting

Output flange

These are typical figures for this type of unit, shown so you can see the shape of the range. Confirm the exact specification with us before ordering.

Typical applications

• Machine mounted drives
• Rotary tables
• Filling machinery
